Horizontal Shaft Engines
GX50
The GX50 engine is a suitable power source for handheld applications like brush-cutters and non-handheld applications like concrete screeds, tillers and pumps. This engine is a perfect replacement for the 2-stroke engines in various applications.
Engine features:
The world's first 360° inclinable 4-stroke engine, for operation in any position
The OHC design driven by a maintenance-free, low-noise timing belt, makes the engine more compact and light
Easy starting, low noise and superb acceleration
High quality materials and purpose-built components ensure reliable long-term use
Meets world's most stringent environmental legislation
Low fuel and oil consumption
Specifications
| Model | GX50 |
| Type | 4-stroke single cylinder OHC petrol engine |
| Bore & Stroke | 43 x 33 mm |
| Displacement | 48 cc |
| Compression Ratio | 8.0:1 |
| Net Power | 1.47 kW ( 2.0 HP ) / 7000 rpm |
| Max Net Torque | 2.2 Nm ( 0.22 kgfm ) / 5000 rpm |
| Ignition System | Transistorised |
| Starting System | Recoil Starter |
| Fuel Consumption at Rated Power | 0.7 L/h 7000 rpm |
| Lubrication System | Oil mist |
| Oil Capacity | 0.13 litres |
| Fuel Tank Capacity (Litres) | 0.63 litres |
| Dry Weight | 4.13 kg approx. |
| Length | 199 mm |
| Width | 260 mm |
| Height | 263 mm |
